Auto car lift plans
| Product no.: | AD30 |
| Your price: | $120.00 |
Auto Car Lift PLANS
220V 60HZ 1PH 3HP POWER UNIT.
Driving Mode:
•Dual hydraulic cylinders, chain drive.
Symmetrical Arm Assembly:
·Tool Tray , It is a convenient storage of Wheel Bolt and Nut on each Arm, there are four tool trays. (Please see Product detail photo above)
·Straight Front / Rear 2 Stage reach from 30-4/5" to 47-1/5"
·Equal length of Front and Rear arm design
·Drop-in type lifting pads, truck adapters included
Safety Mechanism:
•Double Point Safety Lock Release
•Automatic arm lock restraints
•Relief valve built in power pump to prevent overloading
•Door guards protection rubber
•Up-limit switch to protect cylinders working stroke used in safe length scope
•Heavy duty 3/8" diameter cable and 5" pulley reduce high stress on synchronization process and increase cable life
•Stiffened base plate 5/8" thickness
•Ultra high molecular self lubricating nylon slider ensures carriage smooth moving up and down
•Anchor bolts/mounting hardware included
Control System
•Lifting operation by pressing "UP" button on motor
•Manual lowering operation by pressing lever
•Relief valve built in power pump to prevent overloading
•2 sets truck adapters included
•Lifting Capacity: 10,000 lbs
•The overall Height 113-3/4"
•The overall Width 134-5/8"
•Column Width 10.87"
•Base Width 17.95"
•Column Thickness of Steel 3/16"
•Carriage Thickness of Steel 7/32"
•Arms Thickness of Steel 7/32"
•Arm Reach 30-4/5"～47-1/5"
•Min pad height: 3-5/8"
•Lift height max: 70-7/8"
•Drive-thru width clearance: 99-1/2"
•Time to full rise: 50 sec
•Weight: 1400 lbs
